Krone MX 310 GL - Lubrication Points (GL)

Maintenance – lubrication chart
217
14.4 Lubrication points (GL)
The following table contains a list of lubrication points on the machine and the number of
lubrication nipples.
Lubrication points Number of
lubrication
points
1) Bearing for the conveyor drum right + left (MX310/MX350) 2 / 1
2) Parking brake lever 1
3) Steering knuckle of the steering axle (optional additional equipment) 4
4) Locking cylinder of the steering axle (optional additional equipment) 2
5) Floor conveyor, rear 4
6) Compensatory swing (right/left) (for longitudinal control unit only) 2
7) Tandem axle - brake shaft / automat. linkage setter 8/4
8) Floor conveyor, front 4
9) Guide wheel arm for pick-up 2
10) Guide wheel for pick-up 2
11)
12) Main drive PTO shaft 8
13) Hitch (for revolving hitch only) 1
14) Chain lubrication system for rotor drive chain (MX 310 only) 1
