Krone MX 310 GL - Raise;Lower Pick-Up

Medium Control Unit
62
Pos: 19.24 /BA/I nfo-Center/La dewagen/Mediu m/Pick up he ben/senken @ 2 8\mod_12499 72511942_78. doc @ 272641
8.10 Raise/lower pick-up
Figure 28
Raise pick-up
• By pressing the key (10), the pick-up raises as long as the key is being
pressed (pilot lamp (10) is lit as long as the key (10) is being pressed).
Lower pick-up
• By pressing the key 9 once, the pick-up lowers to the float position
(pilot lamp (9) is lit).
By pressing the key (9) again, the float position will be deactivated (pilot lamp (9) goes out).
