9.8 Buttons on the Machine
Warning!
Unexpected actions on the machine
Effect: Injuries or damage to the machine.
• When activating the raise/lower blade bar button, make certain there is
no one in the swivel range of the blade bar.
• Repair, upkeep, maintenance and cleaning work may be performed only
when the machine is at a standstill.
• Switch off the engine, remove the ignition key and turn off the electrical
system on the control box
• Secure the machine and tractor against the possibility of rolling back.
L400631
2
Figure 58:
The machine has two buttons located externally on the machine that can be used to perform
functions on the machine.
The two buttons are located on the left front of the machine and have the following functions:
(1) Raise blade bar
• (2) Lower blade bar
