Medium Control Unit
55
Pos: 19.9 /BA/In fo-Center/Sc hwader/Bedienei nheit - Medium/ Spannungs versorgung @ 2\m od_120307 2066010_78.doc @ 65050
8.3 Electrical power supply
Danger! - Failure of the control unit
Effect: Danger to life, injuries or damage to the machine.
During assembly, make certain that the connection cables are not tight or come in contact with
the tractor wheels.
SW1000007
2
1
Figure 21
Connect the power supply cable (12 V) to the 3-pin power outlet on the tractor and machine
side (DIN 9680).
