13.28 Chain tension
Pos: 31.32 /BA/ Wartung/Ladew agen/Antrieb F örderaggregat @ 14\mod_12 31314279520 _78.doc @ 17 1633
13.28.1 Drive conveyor unit
TR000005_1
X
Figure. 136:
The drive of the conveyor unit is located on the front left side of the machine. Length of spring
under tension X = 85 - 90 mm
Note
Measured up to the top of the washer
