Krone MX 310 GL - Menu 1-3 Axle Suspension (Optional)

Comfort Control Unit
101
Pos: 21.11.13 / BA/Info-Center/L adewagen/H auptmenüs/Ha uptmenü 1 Einst ellungen/Menü 1-3 Achsfeder ung (optional) 1/2 @ 0\mod_1 200660640365 _78.doc @ 46 657
9.10.3 Menu 1-3 "Axle suspension" (optional)
L400080
Figure 65
Setting of the axle suspension.
When the machine is switched on, the axle suspension is in automatic mode. The automatic
mode will be deactivated and changed to manual mode if the cylinder in not in set-point position
or an error has occurred. Additionally, the following message will appear: "Error axle
suspension".
Displaying the menu
Bring up main menu 1 "Settings"
• You can select menu 1-3 with the rotary potentiometer. The icon is shown in
reverse colours.
• Press the rotary potentiometer.
The display shows menu 1-3 "Axle suspension".
Status (state)
= Axle suspension in automatic mode
= Axle suspension inactive (manual mode)
• = Wagon is raised (manual mode)
• = Wagon is lowered (manual mode)
• = Error axle suspension perform axle suspension sensor/actuator test
(see Section “Axle suspension sensor/actuator test”)
