Krone MX 310 GL - Position of Sensors (D;GD) (Left-Hand Side of the Machine)

Maintenance
194
Pos: 31.19.3 /B A/Wartung/La dewagen/Sens oren/AX (D/GD) Lage der Sens oren linke Maschi nenseite @ 2\mod_12035 99309736_78. doc @ 67253
13.17 Position of sensors (D/GD) (left-hand side of the machine)
2
3
AX000011
4
1
Figure 125:
Item Sensor designation Tightening torque
1 Axle locked (B7) (optional) 10 Nm
2 Automatic loader (B2) (Comfort) (optional) 10 Nm
3 Buttons - blade bar (raise/lower) (Comfort) 10 Nm
4 PTO speed 10 Nm
