Commissioning
40
Pos: 12.22.7 /B A/Erstinbetrie bnahme/Ladew agen/Längenanp assung_Te xt_bei Option Aufla ufbremse @ 1\mod_12016 95116341_78.do c @ 53715
For the overrun brake option:
Note
Take into account the lift of the drawbar when braking.
• Pull the PTO shaft apart.
• Push a PTO shaft half (1) onto the PTO of the tractor.
• Push on a PTO shaft with overload protection (2) on the machine side.
• Measure the overlap and make the length adjustment as described in the enclosed
operating instructions of the PTO shaft manufacturer.
Note
The minimum overlap of the PTO shaft must also be ensured when the offset drawbar is raised.
