Lenze i950

Address Name / seng range / [default seng] Info
0x2D01:003 Touch probe (TP) me stamp: Touch probe 2-rising
edg
e me stamp
•
Read only: x ns
Display of the me stamp of the rising edge for touch probe 2.
0x2D01:004 Touch probe (TP) me stamp: Touch probe 2-falling
edge me stamp
•
Read only: x ns
Display of the me stamp of the falling edge for touch probe 2.
0x2D01:005 Touch probe (TP) me stamp: Touch probe 3-rising
edg
e me stamp
•
Read only: x ns
Display of the me stamp of the rising edge for touch probe 3.
0x2D01:006 Touch probe (TP) me stamp: Touch probe 3-falling
edg
e me stamp
•
Read only: x ns
Display of the me stamp of the falling edge for touch probe 3.
0x2D01:007 Touch probe (TP) me stamp: Touch probe 4-rising
edge me stamp
•
Read only: x ns
Display of the me stamp of the rising edge for touch probe 4.
0x2D01:008 Touch probe (TP) me stamp: Touch probe 4-falling
edge me stamp
•
Read only: x ns
Display of the me stamp of the falling edge for touch probe 4.
0x60BA Touch probe pos1 pos value
•
Read only: x pos. unit
Touch probe posion 1 detected with rising edge.
0x60BB Touch probe pos1 neg value
•
Read only: x pos. unit
Touch probe posion 1 detected with falling edge.
0x60BC Touch probe pos2 pos value
•
Read only: x pos. unit
Touch probe posion 2 detected with rising edge.
0x60BD Touch probe pos2 neg value
•
Read only: x pos. unit
Touch probe posion 2 detected with falling edge.
9.7 Setpoint diagnoscs
The following parameters provide informaon on the setpoints set for posion control.
Parameter
Address Name / seng range / [default seng] Info
0x6062 Posion demand value
•
R
ead only: x pos. unit
Display of the interpolated setpoint posion for the posion control.
0x6063 Posion actual internal value
•
Read only: x incr.
Display of the current posion in the internal unit.
0x60FC Posion demand internal value
•
Read only: x incr.
Display of the interpolated setpoint posion for the posion control in
the internal unit.
0x60FA Control eort
•
R
ead only: rpm
Display of the actuang signal (setpoint speed) of the posion controller.
Congure
posion control
Setpoint diagnoscs
170
