Lenze i950

19.22 Connecon to the applicaons
19.22.1 Inputs
P
arameter
Address Name / seng range / [default seng] Info
0x2118:001 SD-In: Sensor type: SD-In1: Sensor type
•
R
ead only
0 Input disabled
1 Passive sensor
2 Acve sensor
0x2118:002 SD-In: Sensor type: SD-In2: Sensor type
•
Read only
0 Input disabled
1 Passive sensor
2 Acve sensor
0x2118:003 SD-In: Sensor type: SD-In3: Sensor type
•
Read only
0 Input disabled
1 Passive sensor
2 Acve sensor
0x2118:004 SD-In: Sensor type: SD-In4: Sensor type
•
Read only
0 Input disabled
1 Passive sensor
2 Acve sensor
0x2119:001 SD-In: Discrepancy me: SD-In1: Discrepancy me
•
R
ead only: x ms
0x2119:002 SD-In: Discrepancy me: SD-In2: Discrepancy me
•
Read only: x ms
0x2119:003 SD-In: Discrepancy me: SD-In3: Discrepancy me
•
Read only: x ms
0x2119:004 SD-In: Discrepancy me: SD-In4: Discrepancy me
•
R
ead only: x ms
0x211A:001 SD-In: Input delay: SD-In1: Input delay
•
R
ead only: x ms
0x211A:002 SD-In: Input delay: SD-In2: Input delay
•
Read only: x ms
0x211A:003 SD-In: Input delay: SD-In3: Input delay
•
Read only: x ms
0x211A:004 SD-In: Input delay: SD-In4: Input delay
•
Read only: x ms
0x211B Input image
•
Read only
Bit 0 SD-In1 channel A
Bit 1 SD-In1 channel B
Bit 2 SD-In2 channel A
Bit 3 SD-In2 channel B
Bit 4 SD-In3 channel A
Bit 5 SD-In3 channel B
Bit 6 SD-In4 channel A
Bit 7 SD-In4 channel B
Bit 16 AIE
Bit 17 AIS
Bit 24 IRS
Bit 25 IRL
Bit 31 Buon S82
Safety
funcons
Connecon to the applicaons
Inputs
442
