5.4 Motor data
The term "motor data" comprises all parameters only depending on the motor and only char-
act
erising the electrical behaviour of the motor. Motor data are independent of the applica-
on in which the inverter and the motor are used.
Precondions
The equivalent circuit data ("Sengs" tab, path: "Basic seng\motor", parameterisaon dia-
log "Derived motor properes and equivalent circuit") apply to a motor in star connecon. In
case of a motor in delta connecon, the delta values must be converted into equivalent star
values.
Possible sengs
If a Lenze motor is connected to the inverter, you can select the motor in the engineering tool
from the "motor catalogue".
•
For details see chapter "Select motor from motor catalogue". ^ 39
Otherwise the motor data must be set manually (for details see chapter "Manual seng of
the motor data“). ^ 41
Parameter
Address Name / seng range / [default seng] Info
0x2C08 Method for seng motor parameters Representaon of the method selected for seng the motor parame-
t
ers. (Is used by the engineering tools.)
1 Select from catalogue (Lenze motors)
2 Enter motor nameplate data (other motors)
3 Manual input (other motors)
4 Idencaon run (all motors)
Basic
seng
Motor data
