Lenze i950

16.2 EtherCAT
EtherCAT® (Ethernet for Controller and Automaon Technology)is an Ethernet-based eldbus
system which
fulls the applicaon prole for industrial realme systems.
•
E
therCAT® is a registered trademark and patented technology, licensed by Beckho Auto-
maon GmbH, Germany.
•
De
tailed informaon on EtherCAT can be found on the web page of EtherCAT Technology
Group (ETG): hp://www.ethercat.org
•
Informaon about the dimensioning of an EtherCAT network can be found in the congu-
raon document for the inverter.
Precondions
•
The in
verter is equipped with the EtherCAT opon.
•
For commissioning, the »PLC Designer« and current device descripon les for EtherCAT
ar
e available:
•
Download »PLC Designer«
•
Download XML/ESI les for Lenze devices
Precondions
The inverter is equipped with the "EtherCAT" network opon.
Typical topology
Line
IN OUT
M
R
SDn
SD2
SD1
IN OUT IN
M Master
SD Slave Device
Conguring the network
E
therCAT
334
