Lenze i950

16.3.7 PROFIsafe
PROFIsafe via PROFINET enables the transfer of safe informaon via the PROFIsafe protocol
acc
ording to the specicaon "PROFIsafe - Prole for Safety Technology", version 2.0.
•
The PR
OFIsafe data is transmied in the second slot of a PROFINET telegram.
•
In the PR
OFIsafe data, one bit each is used to control a certain safety funcon.
•
The s
tructure of the PROFIsafe data is described in the PROFIsafe prole.
•
The length of the PROFIsafe data (also "PROFIsafe message") is xed at 16 bytes.
•
The in
verter forwards the PROFIsafe messages to the safety module (Extended Safety) for
a safe evaluaon.
16.3.8 PROFIenergy
The device prole PROFIenergy enables an energy management for systems. With the support
of the "PROFIenergy Class 3", the energy saving funcon of the inverter can be triggered and
certain energy consumpon values can be measured via standardised commands.
Parameter
Address Name / seng range / [default seng] Info
0x2590:003 Energy saving: State of actual energy saving mode
•
R
ead only
Bit 0 StateOperate
Bit 4 StatePause
Bit 6 StateOperate
16.3.8.1 Supported commands
The following PROFIenergy commands are supported:
Command Descripon
Start_PauseStart_Pause Starts the energy saving funcon.
End_Pause Stops the energy saving
funcon.
Query_Mode Requests the list of all supported energy modes.
Get_Mode Requests the data of an energy mode.
PEM_Status Requests the current status.
PEM_Status_with_CTTO Requests the current status of dynamic values.
PE_Idenfy Requests basic informaon on the modes.
Query_Version Requests the versioning of the query.
Get_Measurement_List Requests the list of the supported measured values.
Get_Measurement_List_with_object_number Requests the list of supported measured values indicang the corre-
sponding par
ameters.
Get_Measurement_Values Requests the values of the measured values.
Get_Measurement_Values_with_object_number Requests the values of the measured values indicang the correspond-
ing parameters.
PE_Mode_ID Manufacturer-specic energy saving mode
The energy saving mode is only acve if the power secon is inhibited.
(0x2590:003 = 1)
16.3.8.2 Supported measured values
The standardised measured values are supported:
ID Measured value Descripon
34 Acve power in W Acve power
205 Acve energy sum in kWh Corresponds to the current value from parameter 0x2DA3:002. The value can be reset by wring.
Conguring the network
PR
OFINET
PROFIenergy
