Lenze i950

7.7 Posion clutch
A path-based clutch is used for the posion clutch.
The Clut
ch engagement mode parameter species whether the clutch operates synchro-
nously or asynchronously. 40x5041:029
•
P
arameter = 0 to acvate synchronous clutch. 40x5041:029
The clut
ch synchronises the posion of the drive axis to the master posion.
The duraon of the clutch engagement process depends on the relaon between the ini-
al situaon of the posions and the master and drive axis velocies.
•
P
arameter = 1 to acvate asynchronous clutch. 40x5041:029
The clut
ch synchronises the velocity of the drive axis to the master velocity.
The clutch engagement process starts aer acvaon. Aer the clutch process, the oset
between the posion of the drive axis and the posion of the master axis is constant. The
oset can be eliminated by seng the parameter Control signals bit 18 = TRUE The posi-
on oset parameters make it possible to reduce the oset to 0. 0x5040:010
Parameter
Address Name / seng range / [default seng] Info
0x5041:020 Stretch factor - numerator
-2147483648 ... [1] ... 2147483647
0x5041:021 Stretch factor - denominator
-2147483648 ... [1] ... 2147483647
0x5041:029 Clutch-in mode
false Synchronous
true Asynchronous
0x5041:031 Clutch mode
5 Path-based
0x5041:033 Declutch posion
0.0000 ... [0.0000] ... 214748.3647
0x5041:034 Deceleraon of "direct declutching"
0.0000 ... [10000.0000] ... 214748.3647
0x5041:035 Clutch-in distance
0.0000 ... [90.0000] ... 214748.3647
0x5041:036 Declutch distance
0.0000 ... [90.0000] ... 214748.3647
0x5041:042 Clutch jerk
0.0000 ... [10000.0000] ... 214748.3647
0x5041:043 Clutch base velocity
•
R
ead only
0x5042:018 Set posion with oset
•
R
ead only
0x5042:019 Set velocity with oset
•
Read only
0x5042:020 Set posion
aer measuring system alignment
•
Read only
0x5042:021 Set velocity aer measuring system alignment
•
Read only
0x5042:031 Clutch posion oset
•
R
ead only
0x5042:035 Set base velocity
•
R
ead only
0x5042:039 Slave set posion
•
R
ead only
0x5042:040 Slave set velocity
•
R
ead only
Conguring the "Sync and Correcon" TA
Posion clutch
123
