Lenze i950

Address Name / seng range / [default seng] Info
0x2451:003 Engineering port sengs: Gateway
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
Seng of the gateway address.
Ex
ample:
The seng 276344004 corresponds to the gateway address
196.172.120.16.
•
276344004 = 0x1078A
CC4 à 0xC4.0xAC.0x78.0x10 = 196.172.120.16
0x2451:004 Engineering port sengs: DHCP Use (enable) of the Dynamic Host Conguraon Protocol (DHCP).
0 Disabled
1 Enabled
0x245B:001 System me: Time base
0 NTP
1 EtherCAT distributed clock
2 Manual input
0x245B:002 System me: Current
me
0 ... [] ... 18446744073709551615 ns
15.2 NTP server addresses
P
arameter
Address Name / seng range / [default seng] Info
0x245A:001 NTP server addresses: Acvate NTP server addresses
0 No acon/no error
1 Restart with current values
10 In progress
11 Acon cancelled
12 Fault
0x245A:002 NTP server addresses: NTP server address 1
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
0x245A:003 NTP server addresses: NTP server address 2
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
0x245A:004 NTP server addresses: NTP server address 3
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
0x245A:005 NTP server addresses: NTP server address 4
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
15.3 Diagnoscs
The network
sengs can be diagnosed as follows:
Parameter
Address Name / seng range / [default seng] Info
0x2452:001 Acve engineering port sengs: IP address
•
R
ead only
Display of the acve IP address.
0x2452:002 Acve engineering port sengs: Subnet
•
Read only
Display of the acve subnet mask.
0x2452:003 Acve engineering port sengs: Gateway
•
Read only
Display of the acve gateway address.
0x2452:005 Acve engineering port sengs: MAC address
•
Read only
Display of the MAC-ID.
Congure engineering port
Diagnoscs
314
