16.4 EtherCAT system bus
The system bus enables the use of several inverters of the i900 series in a network.
The system bus of the inverter uses the EtherCAT® protocol.
•
E
therCAT® is a registered trademark and patented technology, licensed by Beckho Auto-
maon GmbH, Germany.
•
De
tailed informaon on EtherCAT can be found on the web page of EtherCAT Technology
Group (ETG): hp://www.ethercat.org
•
Informaon about the dimensioning of an EtherCAT network can be found in the congu-
raon document for the inverter.
Precondions
•
Only in
verters of the i900 series are connected to the system bus.
•
A maximum of 16 nodes including the master can be connected via the system bus.
•
No further accessories are connected to the system bus.
•
The inverters are not parameterised as CiA 402 moon drives. Selecon of a technology
applicaon: 40x4000
•
The »E
ASY Starter« does not allow a conguraon of the system bus cross communicaon.
The technology applicaon set in the inverter is not idened.
Details
•
The in
verter can act as a system bus master or system bus slave.
•
The system bus is prepared, i. e. a conguraon is not required.
•
The mas
ter assigns an idencal master value to all system bus nodes (slaves).
•
The »EASY Starter« is sucient ...
•
to parameterise the devices in the network;
•
to congure the process data individually.
•
Download »EASY Starter«
•
If further EtherCAT-compliant devices are to be used in addion to the inverters, the bus
conguraon must be adapted to the »PLC Designer«.
•
Download »PLC Designer«
•
Download XML/ESI les for Lenze devices
•
Detailed informaon regarding the adaptaon of the EtherCAT conguraon with
the »PLC Designer« can be found here:
•
Online help »EASY Starter«/»PLC Designer«, topic "Controller-based Automaon Ether-
CAT"
•
Communicaon manual "Controller-based Automaon EtherCAT" (PDF)
Conguring the network
E
therCAT system bus
