Lenze i950

Address Name / seng range / [default seng] Info
0x2C52:002 Load encoder/master encoder sengs (encoder):
Supply v
oltage
5.0 ... [5.0] ... 12.0 V
•
Seng can only be changed if the inverter is inhibi-
ted.
Seng of the supply voltage.
12.2.3.1 SinCos encoder
The following SinCos encoder types without HIPERFACE® protocol are supported by the inver-
t
er:
Type Increments/revoluon Absolute revoluons
IG1024-5V-V3 (RVS58S) 1024 0
IG2048-5V-S (ITD22) 2048 0
IG2048-5V-S 2048 0
12.2.3.2 SinCos absolute value encoder with HIPERFACE® protocol
The following SinCos encoder types with HIPERFACE® protocol are supported by the inverter:
Type Increments/revoluon Absolute revoluons Type code
0x2C41:001
AM1024-8V-H (SRM50) 1024 4096
(Multurn)
39
AM1024-8V-H (SFM60) 1024 39
AM1024-8V-K2 (SRM50S) 1024 39
AM128-8V-H (SKM36) 128 55
AM16-8V-H (SEL37) 16 71
AM16-8V-H (SEL52) 16 71
AM512-8V-H (SCM70) 512 7
AS1024-8V-H (SRS50) 1024 4096
(Single-turn)
34
AS1024-8V-K2 (SRS50S) 1024 34
AS16-8V-H (SEK37) 16 66
AS16-8V-H (SEK52) 16 66
AS512-8V-H (SCS70) 512 2
Use of non-supported encoder types
If the type code of the encoder used is not listed in the table of supported encoder types, this
enc
oder can be introduced to the inverter via two parameters. 40x2C51:002 40x2C51:003
In this context, please also observe the informaon provided in the parameter
descripon 0x2C41:008.
Parameter
Address Name / seng range / [default seng] Info
0x2822:030 Axis commands: Get load encoder/master encoder
informaon (Hiperface)
Obtain Hiperface informaon from the encoder for applicaon feedback.
0 O/Ready
1 On/Start
2 In process
3 Acon cancelled
4 No access
5 No access (controller inhibit)
0x2C51:001 Hiperface load encoder/master encoder sengs: Type
code detected
•
Read only
Type code read out of the encoder.
This value is "0" if ...
•
a sin/cos encoder is set (0x2C50 = 2);
•
a communicaon error has occurred.
0x2C51:002 Hiperface load encoder/master encoder sengs: Type
code manual input
0 ... [0] ... 255
•
Seng can only be changed if the inverter is inhibi-
ted.
Manual seng of the encoder type code (display in 0x2C51:001).
Conguring the feedback system
Sec
ond feedback system for the techology applicaon
Encoder sengs
218
