Lenze i950

5 Basic seng
This chapter contains the most frequently used funcons and sengs to adapt the inverter to
a simple applicaon based on the default seng.
5.1 Device name
P
arameter
Address Name / seng range / [default seng] Info
0x2001 Device name
["De
vice"]
Any device name (e.g. "Wheel drive") can be set in this object for the
purpose of device idencaon.
5.2 Mains voltage
The rated mains voltage set for the inverter has an impact on the operang range of the inver-
t
er.
Parameter
Address Name / seng range / [default seng] Info
0x2540:001 Mains sengs: Rated mains voltage Selecon of the mains voltage for actuang the inverter.
0 230 Ve
1 400 Ve
2 480 Ve
4 60 V (seng-up
operaon)
10 230 Ve/reduced LU level
11 400 Ve/reduced LU level
12 480 Ve/reduced LU level
0x2540:002 Mains sengs: Undervoltage warning threshold
0 ... [430] ... 800 V
Seng of the warning threshold for monitoring DC bus undervoltage.
•
If the DC bus voltage falls below the threshold set, the inverter out-
puts a warning.
•
The warning is reset with a hysteresis of 10 V.
0x2540:003 Mains sengs: Undervoltage error threshold
•
Read only: x V
Display of the xed error threshold for monitoring DC bus undervoltage.
•
If the DC-bus voltage falls below the threshold displayed, the "Error"
response is triggered.
0x2540:004 Mains sengs: Undervoltage reset threshold
•
Read only: x V
Display of the xed reset threshold for monitoring DC bus undervoltage.
0x2540:005 Mains sengs: Overvoltage warning threshold
0 ... [795] ... 800 V
Seng of the warning threshold for monitoring DC bus overvoltage.
•
If the DC bus voltage exceeds the threshold set, the inverter outputs a
warning.
•
The warning is reset with a hysteresis of 10 V.
0x2540:006 Mains sengs: Overvoltage error threshold
•
Read only: x V
Display of the xed error threshold for monitoring the DC bus overvolt-
age.
•
If the DC-bus voltage exceeds the threshold displayed, the "Fault"
response is triggered.
0x2540:007 Mains sengs: Overvoltage reset threshold
•
Read only: x V
Display of the xed reset threshold for monitoring DC bus overvoltage.
0x2540:008 Mains sengs: DC link voltage crical
•
R
ead only
Display of value "1": the DC-bus voltage has reached a crical value.
5.3 Funcon assignment of the inputs and outputs (default seng)
"I/O e
xtensions and control connecons" describes the assignment of funcons to inputs and
outputs. ^ 307
Basic seng
Funcon assignment of the inputs and outputs (default seng)
37
