7.8.4 Gearbox factor correcon
Modied register properes lead to a changed, real register length. The dierence to the par-
ame
terised register length Sensor distance leads to correcons in always the same direcon
(posive or negave). 40x5041:001
This correcon is inecient and leads to increased energy consumpon and increased
mechanical stress. The gearbox factor correcon calculates the opmum setpoint velocity of
the master value in this case.
The correcon value is determined from the mean value of the posion errors. The correcon
value aects the setpoint velocity of the master value axis. When the gearbox factor is adjus-
ted, the constant part of the posion errors is eliminated and the correcon is made in the
posive and negave direcons.
If the selected gain is too high, this can lead to an excessive setpoint velocity.
Parameter name Parameter index Status Funcon
Acvaon of gearbox factor correcon 0x5041:016 TRUE Acvates gearbox factor correcon
Gearbox factor correcon gain 0x5041:011 - Aects the velocity at which the gearbox
factor correcon adjusts the stac error
Actual gearbox factor 0x5042:005 - Outputs the value of the gearbox factor
Max. gearbox factor correcon 0x5041:012 - Species the maximum value of the gearbox
factor correcon
When the corrected gearbox factor has been detected, correcve movements occur in the
posive and negave direcons. The detected gearbox factor is permanently accepted with
bit 25 = TRUE of the Acvaon of gearbox factor correcon parameter. 0x5041:016
If the parameter Acvaon of gearbox factor correcon = FALSE, the value of the gearbox
factor can be modied. 0x5041:016
Parameter
Address Name / seng range / [default seng] Info
0x5041:016 Acvate gearbox factor correcon
Bit 0 FALSE Gearbox factor correcon deacvated
Bit 1 TRUE Gearbox factor correcon acvated
Parameter
Address Name / seng range / [default seng] Info
0x5042:005 Actual gearbox factor
•
Read only
0x5041:011 Gearbox factor correcon gain
0.0000 ... [0.1000] ... 214748.3647
0x5041:012 Max. gearbox factor correcon
0.0000 ... [10.0000] ... 214748.3647
Conguring the "Sync and Correcon" TA
Mas
ter value correcon (register control)
Gearbox factor correcon
