Lenze i950

17.11 Inverter control word
P
arameter
Address Name / seng range / [default seng] Info
0x2830 Inverter control word
0x0000 ... [0x0000] ... 0xFFFF
The control word serves to inuence the control funcons.
Bit 0 Flying restart completed This bit enables the control to report the acceptance of the recorded
speed t
o the "ying restart" funcon. Thus, the ying restart process is
completed.
Bit 1 Block ying restart TRUE: the ying restart process is blocked.
Bit 4 Set load value TRUE: set load value.
Bit 5 Select new actual posion TRUE: dene new actual posion.
•
Seng/shiing of Posion actual value (0x6064) to Actual posion
start value (0x2983) considering the set resoluon (0x608F:001,
0x608F:002).
•
Mode for seng the actual posion: 0x2984)
Bit 6 Acvate DC-injecon braking or short-circuit
braking
DC-injecon braking or short-circuit braking is acvated via this bit.
Bit 10 Reserved
Bit 11 Reserved
17.12 Access protecon
17.12.1 Brand protecon
Parameter
Address Name / seng range / [default seng] Info
0x2100:001 Brand protecon: PIN set
-1 ... [0] ... 9999999
•
0: no br
and protecon.
•
1 ... 9999999: possible pins.
•
-1: brand protecon is acve.
0x2100:002 Brand protecon: PIN input
-2 ... [0] ... 9999999
•
0: not checked.
•
1 ... 9999999: possible pins.
•
-1: check was successful.
•
-2: check was not successful.
0x2100:003 Brand protecon: Encrypon
0 ... [0] ... 9
Encrypon for brand protecon.
17.13 Switching frequency changeover
The output voltage of the inverter is a DC voltage with sine-coded pulse width modulaon
(PWM). This corresponds by approximaon to a AC voltage with variable frequency. The fre-
quency of the PWM pulses is adjus
table and is called "switching frequency".
Details
The switching frequency has an impact on the smooth running performance and the noise
generaon in the motor connected as well as on the power loss in the inverter. The lower the
switching frequency, the beer the concentricity factor, the smaller the power loss and the
higher the noise generaon.
Parameter
Address Name / seng range / [default seng] Info
0x2939 Switching frequency Selecon of the inverter switching frequency.
Abbreviaons used:
•
"V
ariable": adaptaon of the switching frequency as a funcon of the
current. The carrier frequency is reduced dependent on the heatsink
temperature and the ixt-load.
•
"Fix.": the carrier frequency is xed, no frequency reducon.
•
"Drive-opmised": reduces the capacive currents from the motor to
the earth.
•
"Min. Pv": increases the capacive currents from the motor to the
earth.
1 4 kHz variable / drive-opmised
2 8 kHz variable / drive-opmised
3 16 kHz variable / drive-opmised
5 2 kHz xed / drive-opmised
6 4 kHz xed / drive-opmised
7 8 kHz xed / drive-opmised
8 16 kHz xed / drive-opmised
Device
funcons
Switching frequency changeover
382
