10.3.3 Signal ow (V/f

characterisc control)

PWM

Interpolation

Target velocity

DC-injection braking

Frequency

limitation

Current

limitation

Speed

limitation

V/f

characteristic

Load

adjustment

Slip compensation

Velocity actual value

Oscillation

damping

Current demand value

is limited

Current actual value

Voltage actual value

Output frequency

actual value

Congure speed control

Operang mode "CiA 402 Cyclic sync velocity mode (csv)"

Signal ow (V/f characterisc control)
