Lenze i950

Address Name / seng range / [default seng] Info
0x2C51:003 Hiperface load encoder/master encoder sengs: No.
of periods manual input
1 ... [1] ... 65535
•
Seng can only be changed if the inverter is inhibi-
t
ed.
Manual seng of the number of disnguishable revoluons.
0x2C51:004 Hiperface load encoder/master encoder sengs:
Error response
Selecon of the response for communicaon errors or in the event of an
unknown encoder.
Associated error codes:
•
29570 | 0x7382 - RANLI_CIMES_1000_20911
•
29571 | 0x7383 - RANLI_CIMES_1000_20912
•
65306 | 0xFF1A - RANLI_CIMES_1000_20913
0 No response
1 Fault > CiA402
2 Warning
0x2C51:005 Hiperface load encoder/master encoder sengs:
Serial number
•
Read only
The displayed serial number can be used for idenfying an encoder
change.
0x2C51:006 Hiperface load encoder/master encoder sengs:
Actual posion (raw data)
•
Read only
The encoder-internal posion value is output without being converted.
0x2C51:007 Hiperface load encoder/master encoder sengs: No.
of periods detected
•
Read only
Display of the encoder increment according to encoder nameplate or
type code.
0x2C51:008 Hiperface load encoder/master encoder sengs: Type
code vericaon
•
R
ead only
If an encoder is connected that is not supported by the rmware, it will
be displa
yed here.
In this case, the same response takes place as in case of a communica-
on error. The error can be removed by manually seng the type code
in 0x2C51:002. This serves to signalise to the rmware that the number
of disnguishable revoluons is as well set correctly in 0x2C51:003 by
the user.
0 Unknown - manual data input In this case, the same response takes place as in case of a communica-
on error. The error can be removed by manually seng the type code
in 0x2C51:002. This serves to signalise to the rmware that the number
of disnguishable revoluons is as well set correctly in 0x2C51:003 by
the user.
1 Known - parameterisaon ok
0x2C51:009 Hiperface load encoder/master encoder sengs:
Encoder type
•
R
ead only
Display of the detected encoder type (rotary/linear).
0 Rotave encoder
1 Linear encoder
0x2C51:010 Hiperface load encoder/master encoder sengs: No.
of periods linear encoder
•
Read only: x nm
Display of the period length of the linear encoder.
Conguring the feedback system
Sec
ond feedback system for the techology applicaon
Encoder sengs
219
