Lenze i950

Address Name / seng range / [default seng] Info
0x2388 PROFINET status
•
R
ead only
Bit coded display of the current Bus status.
Bit 0 Inialized The network component is inialised.
Bit 1 Online The network component has established a cyclic I/O communicaon
relaonship to a communicaon partner.
Bit 2 Connected Aer inialisaon, the network component waits for a communicaon
partner and the system power-up.
Bit 3 IP address error The IP address is invalid. Valid IP addresses are dened according to RFC
3330.
Bit 4 Hardware fault
Bit 6 Watchdog elapsed PROFINET communicaon is connuously interrupted in the
"Data_Exchange" state, e.g. by cable break or failure of the IO Controller.
•
PROFINET communicaon changes to the "No_Data_Exchange" state.
When the watchdog monitoring me specied by the IO Controller has
elapsed, the response set in 0x2859:001 is triggered in the inverter.
Bit 7 Protocol error
Bit 8 PROFINET stack ok
Bit 9 PROFINET stack not congured
Bit 10 Ethernet controller fault
Bit 11 UDP stack fault
0x2389:001 PROFINET error: Error 1
•
Read only
The parameter currently contains the error detected on the network.
•
The error values may occur in combinaon with the error values from
parameter 0x2389:002.
0 No error
1 Reserved
2 Unit ID unknown
3 Max. units exceeded
4 Invalid size
5 Unit type unknown
6 Runme plug error
7 Invalid argument
8 Service pending
9 Stack not ready
10 Command unknown
11 Invalid address descriptor
0x2389:002 PROFINET error: Error 2
•
R
ead only
The parameter currently contains the error detected on the network.
•
The error values may occur in combinaon with the error values from
parameter 0x2389:001.
Bit 7 IP address error The IP address is invalid. Valid IP addresses are dened according to RFC
3330.
Bit 8 Staon name problem The staon name must be assigned according to the PROFINET specica-
on.
Bit 9 DataExch le PROFINET communicaon is connuously interrupted in the
"Data_Exchange" state, e. g. by cable break.
•
PROFINET communicaon changes to the "No_Data_Exchange" state.
•
When the watchdog monitoring me specied by the IO Controller
has elapsed, the response set in is triggered in the inverter.
Bit 10 Stack boot error
Bit 11 Stack online error
Bit 12 Stack state error
Bit 13 Stack revision error
Bit 14 Inializaon problem The stack cannot be iniated with the user
specicaons. A reason
might be, e. g., a staon name that does not correspond to the PROFI-
NET specicaon.
Bit 15 Stack init error
Conguring the network
PR
OFINET
Diagnoscs
364
