Lenze i950

Address Name / seng range / [default seng] Info
0x5040:111 Status signals limiter
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Bit 1 SS1 acve Quick stop with subsequent inverter disable is requested.
Bit 2 SS2 acve Quick stop is requested.
Bit 3 SOS acve The "Safe operaonal stop (SOS)" funcon is monitored. The "Safe
operaonal stop (SOS)" funcon is acvated
aer the "Safe stop (SS2)"
funcon has been executed.
Bit 4 SLS1 acve Request limited velocity 1. The travel prole changes in accordance with
the parameters set for Limited velocity 1.
Bit 5 SLS2 acve Request limited velocity 2. The travel prole changes in accordance with
the parameters set for Limited velocity 1.
Bit 6 SLS3 acve Request limited velocity 3. The travel prole changes in accordance with
the parameters set for Limited velocity 1.
Bit 7 SLS4 acve Request limited velocity 4. The travel prole changes in accordance with
the parameters set for Limited velocity 1.
Bit 8 SDpos acve Only a posive direcon of rotaon is permied.
Bit 9 SDneg acve Only a negave direcon of rotaon is permied.
Bit 10 SLI acve The "Safe limited increment (SLI)" funcon is acve.
NOTE: This funcon is not supported in the technology applicaon!
Bit 11 SSE acve The "Safe stop emergency (SSE)" funcon is acve.
Bit 12 Buon S82 acve The "Enable switch (ES)" funcon for the moon funcon in special
operaon is acve.
Note: This funcon is not supported in the technology applicaon!
Bit 13 Operaon modes selector (OMS) acve The "Operaon mode selector (OMS)" funcon was requested for spe-
cial operaon.
Note: This funcon is not supported in the technology applicaon!
Bit 16
Bit 23
0x5040:112 Actual velocity
-214748.3648 ... [0.0000] ... 214748.3647
The current velocity is
specied in [units/s]. The velocity is resolved with
4 decimal places.
0x5040:114 Error code
0 ... [0] ... 4294967295
The current error number is displayed.
0x5040:115 Actual torque
-21474836.48 ... [0.00] ... 21474836.47 Nm
The drive-end actual torque is specied in the [Nm]. The torque is speci-
ed with 2 decimal posions.
0x5040:116 Display value 1
0 ... [0] ... 4294967295
The assigned monitor signal is transmied. Selecon takes place via the
Source monitoring 1 parameter.
0x5040:117 Display value 2
0 ... [0] ... 4294967295
The assigned monitor signal is transmied. Selecon takes place via the
Source monitoring 2 parameter.
Conguring the "Sync and Correcon" TA
In
terface
Status signals
94
