Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 250
Parameter Description
Shape Shape of the groove
Min Depth Minimum depth for a groove to be considered valid.
Min Width Minimum width for a groove to be considered valid. The width is the distance between the
groove corners.
Max Width Maximum width of a groove to be considered valid. If set to 0, the maximum is set to the width
of the measurement area.
Region The measurement region defines the region in which to search for the groove. For a stable
measurement, the measurement region should be large enough to cover some data on the left
and right sides of the groove.
For more information on regions, see Regions on page 201.
