Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 251
Parameter Description
Location
(Groove X and Groove Z
measurements only)
Specifies the location type to return
Bottom - Groove bottom. For a U-shape and open-shape groove, the X position is at the centroid
of the groove. For a V-shape groove, the X position is at the intersection of lines fitted to the left
and right sides of the groove. See algorithm section below for more details.
Left - Groove's left corner.
Right - Groove's right corner.
Select Type Specifies how a groove is selected when there are multiple grooves within the measurement
area.
Maximum Depth - Groove with maximum depth.
Index from The Left - 0-based groove index, counting from left to right
Index from the Right - 0-based groove index, counting from right to left.
Index 0-based groove index.
Filters The filters that are applied to measurement values before they are output. For more
information, see Filters on page 209.
Decision The Max and Min settings define the range that determines whether the measurement tool
sends a pass or fail decision to the output. For more information, see Decisions on page 208.
Anchor Description
X or Z Lets you choose the X or Z measurement of another tool to
use as a positional anchor for this tool.
Anchoring
A measurement must be enabled in the other tool for it to be available as an anchor. The anchor
measurement should also be properly configured before using it as an anchor.
For more information on anchoring, see Measurement Anchoring on page 211.
