Gocator Device Files • 526
Element Type Description
4 – Section
Stream\Id 32u The stream source ID.
RefDirection 32s
Setting for reference side to use:
0 – Left
1 – Right
Edge
ProfilePanelEdge
Element for edge configuration
Measurements\X Round Corner tool
measurement
X measurement.
Measurements\Z Round Corner tool
measurement
Z measurement.
Measurements\Angle Round Corner tool
measurement
Angle measurement.
Features\CenterPoint
Geometric Feature
Circle Center PointFeature.
Features\EdgePoint Geometric Feature Edge PointFeature.
Element Type Description
EdgeType 32s
Edge type:
0 – Tangent
1 – Corner
MinDepth 64f Minimum depth.
MaxVoidWidth 64f Maximum void width.
SurfaceWidth 64f Surface width.
SurfaceOffset 64f Surface offset.
NominalRadius 64f Nominal radius.
EdgeAngle 64f Edge angle.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Edge region.
ProfilePanelEdge
Element Type Description
id (attribute) 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
Round Corner Tool Measurement
