LMI Technologies Gocator 2500 Series User Manual

Gocator Line Profile Sensors: User Manual
Gocator Device Files • 556
Element Type Description
Parameters\RefPoint
GdkParamGeometricFeature
Reference point feature.
Parameters\Feature GdkParamGeometricFeature Reference feature.
Measurements\Measurement
@type=Width
Dimension Measurement
Width measurement.
Measurements\Measurement
@type=Length
Dimension Measurement Length measurement.
Measurements\Measurement
@type=Height
Dimension Measurement Width measurement.
Measurements\Measurement
@type=Distance
Dimension Measurement Distance measurement.
Measurements\Measurement
@type=PlaneDistance
Dimension Measurement Plane distance measurement.
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
@type String Type name of measurement.
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Parameters\WidthAbsolute
(Width measurement only)
GdkParamBool Absolute width enabled boolean.
Parameters\LengthAbsolute
(Length measurement only)
GdkParamBool Absolute length enabled boolean.
Dimension Measurement Child Elements
