Gocator Line Profile Sensors: User Manual
Protocols • 631
Indicator ID Instance Value
Part Backtrack Drops 22009 - Number of parts dropped due to backtracking.
Parts Currently Active 22010 - Number of parts currently being tracked.
Part Length 22011 - Length of largest active part.
Part Start Y 22012 - Start Y position of the largest active part.
Part Tracking State 22013 - Tracking state of the largest active part.
Part Capacity Exceeded 22014 - Part detection part or run capacity has been
exceeded.
Part X Position 22015 - Center X position of the largest active part.
Tool Runtime Minimum 22016 - Minimum time spent for tool to process a sample
Tool Runtime Maximum 22017 - Maximum time spent for tool to process a sample
Tool Runtime Average 22018 - Average time for tool to process a sample
Tool Runtime Percent
Average
22019 - Average percentage of total time spent running this
tool
Value 30000 Measurement ID Measurement Value.
Pass 30001 Measurement ID Number of pass decision.
Fail 30002 Measurement ID Number of fail decision.
Min 30003 Measurement ID Minimum measurement value.
Max 30004 Measurement ID Maximum measurement value.
Average 30005 Measurement ID Average measurement value.
Std. Dev. 30006 Measurement ID Measurement value standard deviation.
Invalid Count 30007 Measurement ID Number of invalid values.
Overflow 30008 Measurement ID
Number of times this measurement has overflown
on any output. Multiple simultaneous overflows
result in only a single increment to this counter.
Overflow conditions include:
-Value exceeds bit representation available for
given protocol
-Analog output (mA) falls outside of acceptable
range (0-20 mA)
When a measurement value overflow occurs, the
value is set to the null value appropriate for the
given protocol's measurement value output type.
The Overflow health indicator increments.
*When the sensor is accelerated, the indicator's value is reported from the accelerating PC.
** When the sensor is accelerated, the indicator's value is the sum of the values reported from the
sensor and the accelerating PC.
