Learning Basic Features
Group
Code
Name
LCD Display
Parameter
Setting
Setting Range
Unit
Operation
Frq
Frequency reference
source
Freq Ref Src
2
V1
0–12
-
In
01
Frequency at
maximum analog input
Freq at 100%
Maximum
frequency
0.00–Max.
Frequency
Hz
05
V1 input monitor
V1 Monitor [V]
0.00
0.00–12.00
V
06
V1 polarity options
V1 Polarity
0
Unipolar
0–1
-
07
V1 input filter time
constant
V1 Filter
10
0–10000
ms
08
V1 minimum input
voltage
V1 volt x1
0.00
0.00–10.00
V
09
V1 output at minimum
voltage (%)
V1 Perc y1
0.00
0.00–100.00
%
10
V1 maximum input
voltage
V1 Volt x2
10.00
0 .00– 12.00
V
11
V1 output at maximum
voltage (%)
V1 Perc y2
100.00
0–100
%
16
Rotation direction
options
V1 Inverting
0
No
0–1
-
17
V1 Quantizing level
V1 Quantizing
0.04
0.00*, 0.04–
10.00
%
* Quantizing is disabled if ‘0’ is selected.
0–10V Input Voltage Setting Details
Code
Description
In.01 Freq at
100%
Configures the frequency reference at the maximum input voltage when a
potentiometer is connected to the control terminal block. A frequency set
with code In.01 becomes the maximum frequency only if the value set in
code In.11 (or In.15) is 100(%).
• Set code In.01 to 40.00 and use default values for codes In.02–In.16.
Motor will run at 40.00Hz when a 10V input is provided at V1.
• Set code In.11 to 50.00and use default values for codes In.01–In.16.
Motor will run at 30.00Hz (50% of the default maximum frequency–
60Hz) when a 10V input is provided at V1.
In.05 V1
Monitor[V]
Configures the inverter to monitor the input voltage at V1.
In.07 V1 Filter
V1 Filter may be used when there are large variations between reference
frequencies. Variations can be mitigated by increasing the time constant, but
this will require an increased response time.
The value t (time) indicates the time required for the frequency to reach 63%
of the reference, when external input voltages are provided in multiple
steps.
