These parameters are used to configure the gradient level and offset values
of the Output Frequency, based on the Input Voltage.
Inverts the direction of rotation. Set this code to 1 (Yes) if you need the
motor to run in the opposite direction from the current rotation.
Quantizing is useful when you are operating a noise-sensitive system,
because it suppresses any signal noise. However, quantizing will diminish
system sensitivity (resultant power of the output frequency will decrease
based on the analog input).
You can also turn on the low-pass filter using code In.07 to reduce the
noise, but increasing the value will reduce responsiveness and may cause
pulsations (ripples) in the output frequency.
