248
Learning Advanced Features
Code
Description
applied as rpm or mpm set at ADV-63
(Load Spd Unit).
CNF-21–23 Monitor
Line-x
Select the items to be displayed in monitor mode. Monitor mode is
the first displayed mode when the inverter is powered on. A total of
three items, from monitor line-1 to monitor line- 3, can be displayed
simultaneously.
CNF-24 Mon Mode Init
Selecting 1(Yes) initializes CNF-20–23.
Load Speed Display Setting
Group
Code
Name
LCD Display
Parameter
Setting
Setting
Range
Unit
ADV
(M2)
61(40)
Rotation count speed
gain
Load Spd
Gain
-
100.0
1~6000.0
[%]
-
62(41)
Rotation count speed
scale
Load Spd
Scale
0
x 1
0~4
Hz
63(42)
Rotation count speed
unit
Load Spd Unit
2
rpm
0~1
A
Load Speed Display Setting Detail
Code
Description
ADV-61(M2-40)
Load Spd Gain
If monitoring item 24 Load Speed is selected and if the motor spindle
and the load are connected with belt, the actual number of revolutions
can be displayed by calculating the pulley ratio.
ADV-62(M2-41)
Load Spd Scale
Selects the decimal places that monitoring item 24 Load Speed
displays (from x1–x0.0001).
ADV-63(M2-42)
Load Spd Unit
Selects the unit of monitoring item 24 Load Speed. Selects between
RPM (Revolution Per Minute) and MPM (Meter Per Minute) for the
unit.
For example, if line speed is 300 [mpm] at 800 [rpm], set ADV61 (Load
Spd Gain) to "37.5%" to display the line speed. Also, set ADV62 (Load
Sped Scale) to "X 0.1" to display the value to the first decimal point.
And set ADV63 (Load Spd Unit) to mpm. Now, the monitoring item 24
Load Speed is displayed on the keypad display as 300.0 mpm instead
of 800 rpm.
Note
Inverter power consumption
Values are calculated using voltage and current. Electric power is calculated every second and
the results are accumulated. Setting CNF-62 (WH Count Reset) value to 1(Yes) will reset
