LOCATION INDEX
F–7
F
CONTROL SYSTEM
A6E390001074W02
.
A6E3940W500
1 MAF/IAT sensor
(See F–50 INTAKE AIR TEMPERATURE (IAT)
SENSOR INSPECTION)
(See F–51 MASS AIR FLOW (MAF) SENSOR
INSPECTION)
2 TP sensor
(See F–51 THROTTLE POSITION (TP) SENSOR
INSPECTION)
3 MAP sensor
(See F–52 MANIFOLD ABSOLUTE PRESSURE
(MAP) SENSOR INSPECTION)
4ECT sensor
(See F–53 ENGINE COOLANT TEMPERATURE
(ECT) SENSOR REMOVAL/INSTALLATION)
(See F–53 ENGINE COOLANT TEMPERATURE
(ECT) SENSOR INSPECTION
5 CKP sensor
(See F–54 CRANKSHAFT POSITION (CKP)
SENSOR INSPECTION)
(See F–54 CRANKSHAFT POSITION (CKP)
SENSOR REMOVAL/INSTALLATION)
6CMP sensor
(See F–55 CAMSHAFT POSITION (CMP)
SENSOR INSPECTION)
7 Knock sensor
(See F–56 KNOCK SENSOR INSPECTION)
(See F–56 KNOCK SENSOR REMOVAL/
INSTALLATION)
8 Heated oxygen sensor
(See F–56 HEATED OXYGEN SENSOR (HO2S)
INSPECTION)
9 PSP switch
(See F–58 POWER STEERING PRESSURE (PSP)
SWITCH INSPECTION)
10 Clutch switch
(See F–59 CLUTCH SWITCH INSPECTION)
11 Neutral switch
(See F–59 NEUTRAL SWITCH INSPECTION)
12 BARO sensor
(See F–60 BAROMETRIC PRESSURE (BARO)
SENSOR INSPECTION)
13 PCM (U.K. specs.)
(See F–43 PCM REMOVAL/INSTALLATION)
(See F–45 PCM INSPECTION)
(See F–50 PCM CONFIGURATION)
14 PCM (L.H.D.)
(See F–43 PCM REMOVAL/INSTALLATION)
(See F–45 PCM INSPECTION)
(See F–50 PCM CONFIGURATION)
To Next Page
