Mazda 2002 6 - High-Mount Brake Light Removal;Installation

T–36
EXTERIOR LIGHTING SYSTEM
2. Pleace the bracket in the proper position as
shown in the figure and press it to the trunk lid
(liftgate) to attach.
End Of Sie
HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION
A6E811251580W01
4SD
In-vehicle-type
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
Rear spoiler type
1. Disconnect the negative battery cable.
2. Remove the rear spoiler. (See S–54 REAR SPOILER REMOVAL/INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
A6E8112W121
1 Connector
2 High-mount brake light
3Socket
4 High-mount brake light bulb
A6E8112W123
1Bolt
2Cover
2 High-mount brake light (See T–37 High-mount brake
light removal note)
A6E8112W115
