THERMOSTAT
E–7
E
THERMOSTAT REMOVAL/INSTALLATION
A6E361815171W01
1. Remove the plug hole plate.
2. Disconnect the negative battery cable.
3. Drain the engine coolant. (See E–3 COOLING SYSTEM SERVICE WARNINGS.)
4. Remove the drive belt. (See B–3 DRIVE BELT REPLACEMENT.)
5. Remove the washer tank.
6. Remove the P/S oil pump.
Note
• Remove the P/S oil pump with hoses and pipe still connected.
7. Remove in the order indicated in the table.
8. Install in the reverse order of removal.
9. Refill the engine coolant. (See E–4 ENGINE COOLANT REPLACEMENT.)
10. Inspect the engine coolant leakage. (See E–4 ENGINE COOLANT LEAKAGE INSPECTION.)
11.
End Of Sie
THERMOSTAT
AME3618W001
1 Bypass hose
2 Lower hose
3 Thermostat assembly
To Next Page
