BUMPER
S–47
S
FRONT BUMPER REMOVAL/INSTALLATION
A6E772650031W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
Front Bumper Removal Note
1. Pull the front bumper ends (wheel arch) outward to disengage from the bumper slider.
Caution
• If only one side of the front bumper is disengaged from the bumper slider and the bumper falls, it
could be damaged. When disengaging the front bumper from the slider, secure the bumper so that
it does not fall.
2. Remove the front bumper from the body.
BUMPER
1Screw A
2 Fastener A
3Screw B
4Bolt
5 Fastener B
6 Front bumper
(See S–47 Front Bumper Removal Note)
(See S–48 Front Bumper Installation Note)
A6E7726W003
A6E7726W006
To Next Page
