T–12
LOCATION INDEX
WARNING AND INDICATOR SYSTEM
A6E810001067W01
.
End Of Sie
A6E8118W012
1 Instrument cluster
(See T–72 INSTRUMENT CLUSTER REMOVAL/
INSTALLATION)
(See T–73 INSTRUMENT CLUSTER
DISASSEMBLY/ASSEMBLY)
(See T–73 INSTRUMENT CLUSTER
INSPECTION)
(See T–74 INSTRUMENT CLUSTER REPAIR)
(See T–75 INSTRUMENT CLUSTER INPUT/
OUTPUT CHECK MODE)
2 Fuel gauge sender unit
(See T–83 FUEL GAUGE SENDER UNIT
INSPECTION)
3 Oil pressure switch
(See T–84 OIL PRESSURE SWITCH
INSPECTION)
4Horn
(See T–84 HORN REMOVAL/INSTALLATION)
5 Information display
(See T–84 INFORMATION DISPLAY REMOVAL/
INSTALLATION)
To Next Page
