T–172
ON-BOARD DIAGNOSTIC [AUDIO]
End Of Sie
DTC 00:ER03
A6E817566900W16
Diagnostic procedure
End Of Sie
DTC 00:ER04
A6E817566900W17
Diagnostic procedure
End Of Sie
DTC 05:ER01
A6E817566900W18
3 INSPECT CASSETTE DECK
• Clear DTC.
• Insert and eject cassette tape with no defect.
• Start on-board diagnostic test mode.
• Is DTC 00:Er01 displayed?
Yes Replace cassette deck.
No Troubleshooting completed.
STEP INSPECTION ACTION
DTC 00:Er03 Cassette deck
DETECTION
CONDITION
• Base unit detects that reel built into cassette deck does not operate.
POSSIBLE
CAUSE
• Defective cassette tape (tape slack, pinched tape in internal cassette deck)
• Cassette deck malfunction
STEP INSPECTION ACTION
1 INSPECT CASSETTE TAPE
• Inspect condition of cassette tape where
error has occurred.
• Is cassette tape okay?
Yes Go to next step.
No Repair (remove tape slack or repair pinched tape) or
replace cassette tape, then go to next step.
2 INSPECT CASSETTE DECK
• Clear DTC.
• Insert cassette tape with no defect.
• Play cassette tape for 20 seconds or more.
• Start on-board diagnostic test mode.
• Is DTC 00:Er03 displayed?
Yes Replace cassette deck.
No Troubleshooting completed.
DTC 00:Er04 Cassette tape
DETECTION
CONDITION
Note
• When error occurs, error message “CHECK TAPE” is displayed in the LCD.
• Cassette tape is worn out.
POSSIBLE
CAUSE
• Tape wear
• Cassette deck malfunction
STEP INSPECTION ACTION
1 INSPECT CASSETTE TAPE
• Inspect condition of cassette tape where
error has occurred.
• Is cassette tape okay?
Yes Go to next step.
No Replace cassette tape, then go to next step.
2 INSPECT CASSETTE DECK
• Clear DTC.
• Insert cassette tape with no defect.
• Play cassette tape for 20 seconds or more.
• Start on-board diagnostic test mode.
• Is DTC 00:Er04 displayed?
Yes Replace cassette deck.
No Troubleshooting completed.
DTC 05:Er01 CD changer (external type)
DETECTION
CONDITION
• Changer function does not operate.
POSSIBLE
CAUSE
• Defective CD (broken or foreign material)
• Magazine malfunction
• CD changer (external type) malfunction
