DTC 00:Er10 Cassette deck—base unit communication line
DETECTION
CONDITION
• Base unit detects communication error with cassette deck.
POSSIBLE
CAUSE
• Malfunction of connectors between base unit and cassette deck
• Cassette deck malfunction
• Base unit malfunction
STEP INSPECTION ACTION
1 INSPECT CONNECTOR
• Remove cassette deck and inspect
connector for the following.
— Deformation of pin
— Poor connection of female terminal
— Pinching of foreign material
• Is connector okay?
Yes Go to next step.
No Repair connector, then go to next step.
2 VERIFY THAT CASSETTE DECK IS
INSTALLED WITH BASE UNIT
• Install cassette deck and verify its installation
condition.
• Is cassette deck securely installed?
Yes Go to next step.
No Securely install cassette deck, then go to next step.
3 INSPECT CASSETTE DECK
• Clear DTC.
• Turn ignition switch to ACC or ON position
and hold for 3 seconds or more.
• Start on-board diagnostic test mode.
• Is DTC 00:Er10 displayed?
Yes Replace base unit and cassette deck.
No Troubleshooting completed.
DTC 03:Er10 CD player—base unit communication line
DETECTION
CONDITION
• Base unit detects communication error with CD player.
POSSIBLE
CAUSE
• Malfunction of connectors between base unit and CD player
• CD player malfunction
• Base unit malfunction
STEP INSPECTION ACTION
1 INSPECT CONNECTOR
• Remove CD player and inspect connector for
the following.
— Deformation of pin
— Poor connection of female terminal
— Pinching of foreign material
• Is connector okay?
Yes Go to next step.
No Repair connector, then go to next step.
2 VERIFY THAT CD PLAYER IS INSTALLED
WITH BASE UNIT
• Install CD player and verify its installation
condition.
• Is CD player securely installed?
Yes Go to next step.
No Securely install CD player, then go to next step.
3 INSPECT CD PLAYER
• Clear DTC.
• Turn ignition switch to ACC or ON position
and hold for 3 seconds or more.
• Start on-board diagnostic test mode.
• Is DTC 03:Er10 displayed?
Yes Replace base unit and CD player.
No Troubleshooting completed.
