S–12
FRONT FENDER PANEL
FRONT FENDER PANEL REMOVAL/INSTALLATION
A6E771252110W01
1. Disconnect the negative battery cable.
2. Remove the front side turn light.
3. Remove the fender molding. (See S–50 COWL GRILLE REMOVAL/INSTALLATION.)
4. Remove the front bumper. (See S–47 FRONT BUMPER REMOVAL/INSTALLATION.)
5. Remove the front combination light. (See T–26 FRONT COMBINATION LIGHT REMOVAL/INSTALLATION.)
6. Remove in the order indicated in the table.
7. Install in the reverse order of removal.
End Of Sie
FRONT FENDER PANEL
1 Front fender panel
2 Seal plate
A6E7712W001
