EXTERIOR LIGHTING SYSTEM
T–39
T
STEERING ANGLE SENSOR INSPECTION
A6E811266120W03
With DSC
1. Remove the column cover. (See S–84 COLUMN COVER REMOVAL/INSTALLATION)
2. Disconnect the steering angle sensor connector.
3. Connect battery positive voltage to terminal A and ground to terminal F of the steering angle sensor.
4. Turn the steering wheel to the right and left, and
verify that the voltage and pulses at the terminals
are as shown in the figure.
• If not as specified, replace the body of the
combination switch.
End Of Sie
LIGHT SWITCH REMOVAL/INSTALLATION
A6E811266121W01
1. Disconnect the negative battery cable.
2. Remove the column cover. (See S–84 COLUMN COVER REMOVAL/INSTALLATION)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
A6E8112W143
1 Connector
2Screw
3 Light switch
A6E8112W112
To Next Page
