LOCATION INDEX
FRONT SUSPENSION LOCATION INDEX
A6E740001015W01
.
End Of Sie
LOCATION INDEX
A6E7414W033
1 Front shock absorber and coil spring
(See R–9 FRONT SHOCK ABSORBER AND
SPRING REMOVAL/INSTALLATION)
2 Front shock absorber
(See R–12 FRONT SHOCK ABSORBER
INSPECTION)
(SeeR–12 FRONT SHOCK ABSORBER
DISPOSAL)
3 Front upper arm
(See R–13 FRONT UPPER ARM REMOVAL/
INSTALLATION)
(See R–14 FRONT UPPER ARM INSPECTION)
4 Front lower arm (front)
(See R–15 FRONT LOWER ARM (FRONT)
REMOVAL/INSTALLATION)
(See R–18 FRONT LOWER ARM (FRONT)
INSPECTION)
5 Front lower arm (rear)
(See R–19 FRONT LOWER ARM (REAR)
REMOVAL/INSTALLATION)
(See R–21 FRONT LOWER ARM (REAR)
INSPECTION)
6 Front stabilizer
(See R–22 FRONT STABILIZER REMOVAL/
INSTALLATION)
7 Stabilizer control link
(See R–23 STABILIZER CONTROL LINK
INSPECTION)
8 Front crossmember
(See R–23 FRONT CROSSMEMBER REMOVAL/
INSTALLATION)
9 Transverse member
(See R–27 TRANSVERSE MEMBER REMOVAL/
INSTALLATION)
