DOOR
S–15
S
FRONT DOOR REMOVAL/INSTALLATION
A6E771458010W02
1. Disconnect the negative battery cable.
2. To remove the front door hinge, remove the front fender panel.
3. To remove the checker, remove the door speaker.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
6. Adjust the front door. (See S–16 DOOR
ADJUSTMENT.)
Connector Removal Note
1. Push the rubber boot backward.
2. Pull down the cover in the direction indicated by
the arrow and disconnect the connector.
End Of Sie
REAR DOOR REMOVAL/INSTALLATION
A6E771472010W02
Warning
• Handling the side air bag sensor improperly can accidentally deploy the side air bag module,
which may seriously injure you. Read AIR BAG SYSTEM SERVICE WARNINGS before working
around the B-pillar areas. (See T–117 SERVICE WARNINGS.)
Note
• The side air bag sensor is located in the B-pillar.
1. Disconnect the negative battery cable.
2. To remove the checker, turn the rear door speaker.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. Adjust the rear door. (See S–16 DOOR
ADJUSTMENT.)
1 Connector
(See S–15 Connector Removal Note)
2 Front door hinge
3 Front door
4 Checker
A6E7714W006
A6E7714W007
1 Connector
2 Rear door hinge
3 Rear door
4 Checker
A6E7714W023
To Next Page
