K–46
AUTOMATIC TRANSAXLE SHIFT MECHANISM
End Of Sie
INTERLOCK CABLE ADJUSTMENT
BHE051409000W03
1. Turn the ignition switch to ON position (engine OFF).
2. Pull up the lock piece of the interlock cable to
release the lock.
3. Remove the clip of the selector lever base plate,
then remove the interlock cable from the U-
groove.
4. Remove the interlock cable from the selector
lever.
5. Fully pull the end of the interlock cable to the
selector lever.
6. Remove the lock unit from the bracket.
7. Verify that the markings on the slider pin and the
lock unit are aligned.
End Of Sie
A6E5616W010
A6E5616W011
INTERLOCK CABLE
CHU0514W010
INTER LOCK UNIT
SLIDE PIN
MARKING
MARKING
BHE0514W010
To Next Page
