S–104
SEAT BELT
BUCKLE SWITCH INSPECTION
A6E775057620W02
Driver's Seat
1. Disconnect the negative battery cable.
2. Disconnect the buckle switch connector.
3. Inspect for continuity between the buckle switch
terminals using an ohmmeter.
• If not as specified, replace the front buckle.
End Of Sie
CHILD RESTRAINT SEAT ANCHOR REMOVAL/INSTALLATION
A6E77505777ZW01
1. Remove the cover.
2. Remove the bolt and child restraint seat anchor.
3. Install in the reverse order of removal.
End Of Sie
A6E7750W010
A6E7750W009
A6E7750W001
