LOCATION INDEX
T–5
T
POWER SYSTEM
A6E810001072W01
.
LOCATION INDEX
A6E8110W124
1Main fuse
(See T–19 MAIN FUSE REMOVAL/INSTALLATION)
2 Fuse block
(See T–20 FUSE BLOCK REMOVAL/
INSTALLATION)
3 Ignition switch
(See T–20 IGNITION SWITCH REMOVAL/
INSTALLATION)
(See T–20 IGNITION SWITCH INSPECTION)
4 Key reminder switch
(See T–21 KEY REMINDER SWITCH REMOVAL/
INSTALLATION)
(See T–21 KEY REMINDER SWITCH
INSPECTION)
5 Cigarette lighter
(See T–21 CIGARETTE LIGHTER REMOVAL/
INSTALLATION)
(See T–22 CIGARETTE LIGHTER INSPECTION)
6 Cooling fan relay No.2
(See T–24 RELAY INSPECTION)
7Horn relay
(See T–24 RELAY INSPECTION)
To Next Page
