OIL COOLER
D–7
D
D
LUBRICATION SYSTEM
OIL COOLER REMOVAL/INSTALLATION
A6E331819900W01
LF, L3
1. Remove the under cover.
2. Drain the engine coolant. (See E–4 ENGINE COOLANT REPLACEMENT.)
3. Remove the oil filter cover, and drain the engine oil into a container. (See D–6 OIL FILTER REPLACEMENT.)
4. Remove in the order indicated in the table.
5. Use a clean rag to wipe off the mounting surface
on the oil cooler.
6. Install in the reverse order of removal.
7. Inspect the oil level.
• If necessary, add oil. (See D–4 ENGINE OIL
INSPECTION.)
8. Start the engine and inspect for oil leakage.
• If the oil leaks, specify the faulty part and
repair or replace it.
End Of Sie
OIL COOLER
1 Water hose
2 Oil cooler
AME3318W002
