AUDIO AND NAVIGATION SYSTEM
T–99
T
2. While pressing down the unit behind the LCD
unit, pull the LCD unit out from the dashboard.
End Of Sie
AUDIO CONTROL SWITCH REMOVAL/INSTALLATION
A6E812400148W01
Note
• The audio control switch and the cruise control switch use a common connector.
1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See T–120 DRIVER-SIDE AIR BAG MODULE REMOVAL/
INSTALLATION.)
3. Remove the steering wheel.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
End Of Sie
A6E8124W018
1Bolt
2Bracket
3Screw
4 Cover
5Screw
6 Audio control switch/cruise control switch
A6E8124W019
