CHARGING SYSTEM , IGNITION SYSTEM
G–8
Standard current (Reference)
Measuring conditions
Room temperature: 20 °C {68 °F}
Voltage: 13.5 V
Engine hot
* : Must not be 0 A
End Of Sie
IGNITION COIL REMOVAL/INSTALLATION
A6E471218110W01
1. Disconnect the negative battery cable.
2. Remove the plug hole plate.
End Of Sie
Engine
speed
(rpm)
Terminal B current (A)
L8 LF L3
1,000 0*—80
2,000 0*—90
IGNITION SYSTEM
A6E4712W012
1 Connect
2 High-tension lead (See G–10–1 HIGH-TENSION
LEAD REMOVAL/INSTALLATION )
3 Ignition coil
