FLOOR COVERING
S–99
S
FRONT FLOOR COVERING REMOVAL/INSTALLATION
A6E774868670W01
1. Disconnect the negative battery cable.
2. Remove the front seats. (See S–105 FRONT SEAT REMOVAL/INSTALLATION.)
3. Remove the rear seat.
4. Remove the front scuff plates.
5. Remove the rear scuff plates.
6. Remove the console.
7. Remove the front side trims.
8. Remove the B-pillar lower trims.
9. Remove the lower anchor of the front seat belt installation bolts.
10. Remove the tire house trim. (5HB)
11. Remove the fuel-filler lid opener bezel.
12. Remove the fasteners.
13. Remove the cap nuts.
14. Remove the clips.
15. Take the front floor covering off from the passenger-side door opening.
16. Install in the reverse order of removal.
End Of Sie
FLOOR COVERING
A6E7748W001
